XEMIS-003

Next Generation Gas Sorption Analyzer

Versatile pure and mixed gas sorption analyzer

Pure and mixed gas sorption at pressures to 200 bar
Exosensing Technology for operation with aggressive species
Optional mass spectrometer for integrated high pressure TGA

Request a quote Download Brochure

Key features

Dynamic mode for mixed gas analysis
Unique Exosensing Technology for operation with aggressive species
Optimized performance for sample sizes from 1 mg to 5 g

Applications

High pressure catalysis
Flue gas desulfurization
Gas-solid reaction kinetics

Measurement types

High pressure TGA
isothermal and isobaric analysis
Evolved gas analysis

introduction

The XEMIS-003 is a dynamic gas sorption analyzer incorporating multiple controllable inlets with combined pressure and flow control, and the option of integrated mass spectrometry. Changes in sample mass are measured as a function of applied temperature and pressure to determine isotherms, isobars and sorption kinetics. Designed for operation with a full range of gas and vapor species including corrosives and flammables, the XEMIS series features a controllable pressure range covering 7 orders of magnitude.

The XEMIS series offers reproducible, high resolution, high accuracy measurements even with small sample sizes or small uptakes, and performance unrivalled in a high pressure sorption analyzer.

Specifications

Weight

Balance capacity5 g
Weighing range100 mg / 200 mg
Resolution0.1 µg / 0.2 µg
Stability± 1 µg short term ()± 5 µg long term

Pressure

Design pressure170 bar (standard), or 200 bar (optional)
Accuracy± 0.04 % of range
Transducer ranges (up to 4) 1, 10, 20, 50, 200 bar, 100 mbar
Base vacuum at sample< 10⁻⁶ mbar
Setpoint regulation accuracy± 0.02 % of range
Programmable inletsup to 4
Dynamic pressure / flow control
Full scale flow rate3 – 1000 ml/min (as defined by order option)

Temperature

Measurement range77 – 773 K
Temperature sensorsPlatinum Resistance Thermometer (Pt100)
Measurement accuracy± 0.01 K
Setpoint regulation accuracy
Recirculating waterbath± 0.05 K
Furnace options± 0.1 K
Linear ramp TGA option0.05 – 20 K/min programmable
Cabinet (balance) temeprature stability± 0.1 K

System Construction

Wetted componentsAll metal
Pressure vesselStainless steel (316L grade)
Pressure sealsCajon VCR stainless steel
Pressure transducer diaphragmsHastelloy C276 / Inconel 600
Overpressure bursting discLaser welded stainless steel
Corrosive species compatibilityIncluded

Mass Spectrometer Options

Coupling methodHeated Quartz Inert Capillary (QIC) inlet
Atomic mass range1-200 AMU standard (1-300 AMU optional)
Detection limit0.1 to 1 ppm, subject to spectral interference
Better that 20 ppb (Triple Mass Filter option)
DetectorDual Faraday/Electron Multiplier
